70W Solar LED Street Light, 7200 Lumens, 5700K, 180 LM/W, Integrated 18V Monocrystalline Solar Panel, LiFePO4 Battery, Motion Sensor, Dusk-to-Dawn Light Control, 150°×70° Beam, IP66, Die-Cast Aluminum, 4-7M Mounting Height

The 70W Solar LED Street Light is an integrated off-grid lighting solution designed for roadways, pathways, parking areas, farms, campuses, parks, and remote locations where conventional electrical wiring may be difficult or unavailable. It combines a high-efficiency 18V monocrystalline solar panel, 32135 LiFePO4 battery, LUXEON 5050 LEDs, MPPT charging technology, and intelligent lighting controls in a durable die-cast aluminum housing.

Delivering up to 7,200 lumens at 180 LM/W, the fixture provides powerful outdoor illumination while using solar energy generated during daylight hours. Integrated light-sensor, time-control, and motion-sensor functions automatically manage operation and brightness to help conserve stored battery power.

Key Features

• 70W LED Output with up to 7,200 lumens
• 180 LM/W Lighting Efficiency
• 5700K Color Temperature
• 18V Monocrystalline Solar Panel
• 32135 LiFePO4 Battery
• MPPT Tracking Technology for optimized solar charging
• Motion Sensor for intelligent brightness control
• Dusk-to-Dawn Light Sensor for automatic nighttime operation
• Multi-Period Time Control for scheduled lighting
• 150° × 70° Beam Distribution
• 130° Photometric Average Beam Angle
• IP66 Outdoor Protection
• Die-Cast Aluminum Housing
• 4-7M Recommended Installation Height
• 60 mm Pole Diameter
• Black/Grey Housing
• LUXEON 5050 LED Chips
• 20,000+ Hour LED Lifespan
• 2-Year Warranty
• Designed for locations without conventional electrical wiring

Technical Specifications

Integrated Solar Power System

The LS-SLS70W combines the solar panel, battery, LED light source, controller, and lighting controls into a single integrated fixture. The 18V monocrystalline solar panel collects solar energy during the day and stores it in the LiFePO4 battery for nighttime illumination.

The solar panel is specified with conversion efficiency of up to 24%. MPPT tracking technology is used to improve solar energy utilization and system efficiency under changing sunlight conditions.

LiFePO4 Battery System

The fixture uses a 32135 LiFePO4 battery designed for repeated charge and discharge cycles. The product documentation specifies more than 2,200 cycles and a battery service life of more than 25 years under specified conditions, with approximately 80% efficiency.

Actual battery performance and service life can vary according to climate, sunlight exposure, temperature, installation conditions, and operating settings.

Intelligent Motion Sensor Control

The integrated motion sensor provides an energy-saving lighting mode. When movement is detected, the fixture can increase to 100% brightness. When no movement is detected, the light can reduce to a lower brightness level.

The specification indicates an adjustable 10%-100% brightness range and approximately 8-10 meter motion detection distance, depending on environmental and installation conditions.

This allows the fixture to provide higher illumination when people or vehicles approach while reducing power consumption when the area is inactive.

Dusk-to-Dawn & Time Control

The lighting system combines three control methods:

• Light Sensor Control for automatic nighttime activation
• Time Control for scheduled operating periods
• Motion Sensor Control for occupancy-based brightness adjustment

The time-control system can be divided into multiple periods to help balance lighting requirements and available battery capacity.

Outdoor Construction

The fixture uses an integrated die-cast aluminum housing designed for heat dissipation and outdoor durability. Its IP66 rating provides protection against dust and powerful water exposure.

The 70W model is designed for installation heights of approximately 4-7 meters and uses a mounting connection compatible with a 60 mm pole diameter.

Recommended Applications

• Roadway Lighting
• Street Lighting
• Parking Areas
• Sidewalks
• Pathways
• Parks
• Campuses
• Gardens
• Farms & Ranches
• Fences
• Ramps
• Boat Docks
• Remote Areas
• Off-Grid Properties
• Commercial Outdoor Areas

Off-Grid Lighting Solution

Because the fixture generates and stores its own electrical energy, it can provide lighting without a conventional utility power connection. This makes it suitable for remote roads, farms, parks, pathways, campuses, and other locations where installing electrical infrastructure may be difficult.

The integrated design also eliminates the need for a separate external solar panel and battery enclosure.

Installation & Mounting

The fixture is designed for pole mounting with a specified 60 mm pole diameter and approximately 100-105 mm connective section length.

Installation includes:

1. Inspect the fixture and components for shipping damage.
2. Loosen the M8 adjustment screws and set the desired fixture angle.
3. Secure the fixture to the compatible pole using the mounting bracket.
4. Tighten the mounting hardware securely.
5. Confirm the sensor indicator and nighttime operation after installation.

Professional installation is recommended. The solar panel should have clear exposure to sunlight throughout the day.

Important Installation & Storage Notes

For reliable operation:

• Install the fixture where the solar panel receives sufficient direct sunlight.
• Avoid trees, buildings, and other obstructions that create significant shade.
• Do not install the product in high-temperature, enclosed, or poorly ventilated locations.
• Maintain storage temperatures between -25°C and +60°C.
• Working temperature is specified as -20°C to +50°C.
• Stored units should be charged and discharged periodically according to the manufacturer's instructions.
• Faulty products should be serviced by qualified personnel.
• Actual runtime depends on sunlight availability, local weather, temperature, installation conditions, and selected operating mode.

Frequently Asked Questions

How many lumens does the 70W model produce?

The LS-SLS70W produces up to 7,200 lumens at a specified efficiency of 180 LM/W.

What color temperature is available?

This model is specified at 5700K.

Does the light require AC power?

No. It is designed as an integrated solar-powered lighting system using its own solar panel and battery.

What type of battery does it use?

The fixture uses a 32135 LiFePO4 battery.

Does it automatically turn on at night?

Yes. The integrated light sensor provides automatic nighttime operation.

Does it have motion detection?

Yes. The fixture includes a motion sensor that can increase brightness when movement is detected and reduce brightness when the area is inactive.

What is the operating time?

The specification indicates more than 12 hours at full power and approximately 3-4 days in intelligent mode, depending on sunlight and local operating conditions.

What pole diameter is required?

The specification identifies a 60 mm pole diameter for the mounting connection.

What installation height is recommended?

The 70W model is specified for approximately 4-7 meters.

What is the beam angle?

The optical specification lists a 150° × 70° beam distribution, while the photometric data lists an average beam angle of approximately 130°.

Is it suitable for remote locations?

Yes. The integrated solar panel and battery make it suitable for remote and off-grid locations where conventional electrical wiring is unavailable or impractical.

Is it suitable for outdoor use?

Yes. The fixture has an IP66 rating and a die-cast aluminum housing designed for outdoor applications.

What warranty is included?

The product includes a 2-year warranty.
