50W Solar LED Street Light, 4500 Lumens, 5700K, 180 LM/W, Integrated 18V Monocrystalline Solar Panel, LiFePO4 Battery, Motion Sensor, Dusk-to-Dawn Light Control, 150°×70° Beam, IP66, Die-Cast Aluminum, 4-6M Mounting Height

The 50W Solar LED Street Light is a fully integrated, off-grid lighting solution designed for roadways, pathways, parking areas, farms, campuses, parks, and other locations where running electrical wiring may be difficult or impractical. It combines a high-efficiency 18V monocrystalline solar panel, LiFePO4 battery, LUXEON 5050 LED chips, MPPT charging technology, and intelligent motion-sensing controls in a durable die-cast aluminum housing.

Delivering up to 4,500 lumens at 180 LM/W, the fixture provides automatic nighttime lighting without requiring a conventional AC power connection. Its integrated light sensor, time control, and motion sensor can automatically adjust brightness to help extend operating time and optimize battery usage.

Key Features

• 50W LED Output with up to 4,500 lumens
• 180 LM/W Lighting Efficiency
• 5700K Color Temperature
• 18V Monocrystalline Solar Panel
• LiFePO4 Battery using 32135 cells
• MPPT Solar Charging Technology for improved system efficiency
• Intelligent Motion Sensor with adjustable brightness
• Dusk-to-Dawn Light Control through integrated light sensing
• Time-Based Lighting Control with multiple programmable periods
• 150° × 70° Beam Distribution
• IP66 Protection for outdoor applications
• Die-Cast Aluminum Housing
• 4-6M Recommended Installation Height
• 60 mm Pole Diameter
• Black/Grey Housing
• 20,000+ Hour LED Lifespan
• 2-Year Warranty
• Designed for locations without conventional electrical wiring

Technical Specifications

Integrated Solar Power System

The 50W fixture integrates the solar panel, battery, LED system, and controller into one outdoor lighting unit. The 18V monocrystalline silicon solar panel converts sunlight into electrical energy during the day, while the integrated LiFePO4 battery stores energy for nighttime operation.

The solar panel is specified with conversion efficiency of up to 24%, while MPPT tracking technology helps optimize solar energy harvesting under changing sunlight conditions.

LiFePO4 Battery Technology

The fixture uses a 32135 LiFePO4 battery system designed for repeated charging and discharging. The specification indicates more than 2,200 charge/discharge cycles and a battery life of more than 25 years under specified conditions, with approximately 80% efficiency.

Actual operating performance and battery life can vary according to sunlight availability, temperature, installation location, and usage conditions.

Intelligent Motion Sensor Lighting

The integrated motion sensor provides an energy-saving operating mode. When movement is detected, the light can increase to 100% brightness. When no movement is detected, the fixture can reduce brightness to a lower level, with the specification indicating an adjustable 10%-100% brightness range.

The product documentation indicates motion detection at approximately 8-10 meters, depending on installation and environmental conditions.

This operating strategy helps conserve stored battery energy during periods when the area is unoccupied.

Dusk-to-Dawn & Time Control

The solar street light combines three control methods:

• Light Sensor Control for automatic nighttime operation
• Time Control for scheduled lighting periods
• Motion Sensor Control for occupancy-based brightness adjustment

The time-control system can be configured across multiple time periods to balance illumination requirements and battery conservation.

Outdoor Construction

The fixture features an integrated die-cast aluminum housing designed to provide effective heat dissipation and outdoor durability. The IP66 rating provides protection against dust and powerful water jets, making the light suitable for exposed outdoor installations.

The recommended installation height is approximately 4-6 meters, with a 60 mm pole diameter specified for the mounting connection.

Recommended Applications

• Roadway Lighting
• Street Lighting
• Parking Areas
• Pathways
• Sidewalks
• Parks
• Campuses
• Gardens
• Farms & Ranches
• Fences
• Ramps
• Boat Docks
• Remote Areas
• Off-Grid Properties
• Commercial Outdoor Areas

Off-Grid Lighting Solution

Because the fixture generates and stores its own electrical energy, it can be used in locations where trenching, underground wiring, or extending utility power would be difficult or costly.

It is particularly suitable for remote pathways, rural roads, farms, ranches, parks, campuses, and other outdoor areas requiring standalone lighting.

Installation & Mounting

The fixture is designed for installation on compatible poles with a specified 60 mm pole diameter and approximately 100-105 mm connective section length.

The installation process includes:

1. Inspect the fixture and components for shipping damage.
2. Adjust the fixture angle using the M8 adjustment screws.
3. Secure the fixture to the pole using the mounting bracket.
4. Tighten the mounting hardware securely.
5. Confirm the sensor and nighttime operation after installation.

Professional installation is recommended. The solar panel should have unobstructed exposure to sunlight and should not be installed beneath trees or other structures that significantly reduce solar exposure.

Important Installation & Storage Notes

For reliable performance:

• Install the solar panel where it receives sufficient direct sunlight.
• Avoid locations with persistent shade or obstructions.
• Do not install the fixture in high-temperature, enclosed, or poorly ventilated areas.
• Store the product within the specified -25°C to +60°C storage temperature range.
• The documentation recommends charging and discharging stored units every three months.
• Faulty units should be serviced by qualified personnel.
• Actual runtime varies with sunlight, local weather, temperature, and operating settings.

Frequently Asked Questions

Does this solar street light require AC wiring?

No. It is designed as a standalone solar lighting system using an integrated solar panel and battery.

How many lumens does the 50W model produce?

The 50W model is rated at 4,500 lumens.

What color temperature is available?

This model is specified at 5700K.

What type of battery does it use?

It uses a 32135 LiFePO4 battery system.

Does it turn on automatically at night?

Yes. The integrated light sensor provides automatic nighttime activation.

Does it have a motion sensor?

Yes. The fixture includes motion-sensor control that can increase brightness when movement is detected and reduce brightness when the area is inactive.

How long can it operate?

The specification indicates more than 12 hours at full power and approximately 3-4 days in intelligent mode, depending on local sunlight and operating conditions.

What pole diameter is required?

The specification identifies a 60 mm pole diameter for installation.

What installation height is recommended?

The 50W model is specified for approximately 4-6 meters mounting height.

Is it suitable for remote locations?

Yes. Its integrated solar power system makes it suitable for remote areas where conventional electrical wiring is unavailable or impractical.

Is the light waterproof?

The fixture carries an IP66 rating, providing protection against dust and powerful water exposure. Proper installation is still required for long-term outdoor performance.

What warranty is included?

The product includes a 2-year warranty.
