30W/50W/60W 3CCT Selectable Lantern Post Top LED Light, 3000K/4000K/5000K, 120 LM/W, 120-277V AC, 0-10V Dimming, 120° Beam Angle, UL/cUL & DLC Listed, IP65, Black Die-Cast Aluminum Housing, Slip-Fit Mount, 5-Year Warranty

Upgrade outdoor area lighting with the 30W/50W/60W 3CCT Selectable Lantern Post Top LED Light, designed for commercial and architectural outdoor applications. This lantern-style post top fixture combines an elegant appearance with selectable wattage and color temperature, allowing one fixture to adapt to different lighting requirements.

With 120 LM/W efficiency, 120-277V AC input, 0-10V dimming, a 120° beam distribution, and a built-in slip-fit mounting base for 3-inch round poles, it is suitable for parking lots, pathways, shopping centers, dealerships, gardens, and other outdoor spaces.

Key Features

• Selectable Wattage: 30W, 50W, or 60W
• 3CCT Selectable: 3000K, 4000K, or 5000K
• High Efficiency: 120 lumens per watt
• Wide Distribution: 120° nominal beam angle
• 0-10V Dimming: Supports adjustable lighting levels
• Universal Input: 120-277V AC
• Durable Housing: Heavy die-cast aluminum with black powder-coated finish
• High-Quality Optics: Glass lens for reliable outdoor light distribution
• Outdoor Protection: IP65-rated construction
• Easy Pole Installation: Slip-fit mount for 3-inch round poles
• Mounting Height: Suitable for approximately 15-30 ft poles
• Certifications: UL, cUL, and DLC listed
• Long Service Life: Designed for 50,000-hour operation
• Warranty: 5-year limited warranty

Technical Specifications

Selectable Wattage & Color Temperature

Choose the appropriate light output and color temperature during installation to match the requirements of different outdoor spaces.

Wattage options:

• 30W — 3,600 lumens
• 50W — 6,000 lumens
• 60W — 7,200 lumens

CCT options:

• 3000K — Warm White
• 4000K — Neutral White
• 5000K — Daylight White

This flexibility helps contractors and facility managers standardize one fixture across multiple outdoor lighting projects.

0-10V Dimming & Electrical Performance

The fixture supports 0-10V dimming for applications where lighting levels need to be adjusted based on operating conditions, schedules, or project requirements. The universal 120-277V AC input makes it suitable for a wide range of commercial electrical systems.

Durable Lantern-Style Construction

The fixture uses a heavy die-cast aluminum housing with a black powder-coated finish for outdoor durability. A quality glass optical lens provides controlled light distribution while maintaining the traditional lantern-style appearance.

The IP65-rated construction is designed for outdoor environments where protection against dust and water jets is required.

Slip-Fit Pole Mounting

The integrated slip-fit mounting design is made for 3-inch round poles and is suitable for mounting heights from approximately 15 to 30 feet.

Installation involves securing the mount base to the fixture, routing the power connection through the mounting base, sliding the fixture over the pole, and tightening the mounting screws.

Recommended Applications

• Parking Lots
• Commercial Area Lighting
• Auto Dealerships
• Shopping Malls
• Sporting Complexes
• Garden Lighting
• Pathway Lighting
• Pedestrian Areas
• Commercial Properties
• Outdoor Architectural Lighting

Lighting Replacement

The selectable wattage design allows contractors to configure the fixture according to the required light output rather than using separate fixtures for every application. This can simplify product selection and inventory management across commercial outdoor lighting projects.

Bulk & Contractor Purchasing

Ideal for contractors, electrical distributors, property managers, municipalities, and commercial lighting projects requiring consistent post top fixtures across multiple locations.

For larger projects, purchasing multiple fixtures with the same selectable wattage and CCT platform can simplify installation, replacement, and future inventory requirements.

Frequently Asked Questions

Can I change both wattage and color temperature?

Yes. The fixture provides selectable 30W/50W/60W wattage and 3000K/4000K/5000K CCT options.

Does this post top light support dimming?

Yes. It supports 0-10V dimming.

What voltage does this fixture use?

The fixture operates on 120-277V AC.

What type of pole does it fit?

It uses a 3-inch round pole slip-fit mount.

What mounting height is recommended?

The specification indicates mounting heights of approximately 15-30 feet.

Is this fixture suitable for outdoor use?

Yes. The fixture has an IP65 rating and a powder-coated die-cast aluminum housing designed for outdoor applications.

What beam angle does it provide?

The nominal beam angle is 120°, with a listed photometric average beam angle of approximately 108°.

What warranty is included?

The fixture comes with a 5-year limited warranty. Actual performance may vary depending on environmental and application conditions.
